Dome Head Open End Blind Rivet

Open type Blind Rivet
Open type Blind Rivet
Open type Blind Rivet
Open type Blind Rivet
Open type Blind Rivet
Open type Blind Rivet

Dome Head Open End Blind Rivet

Borie Fasteners is a professional fastener manufacturer and supplier, we are committed to providing clients with superior fastening solutions. Blind rivet customized available in material, length, diameter,surface treatment.

  • Standard:

    DIN7337

  • Head Type:

    Dome Head/Countersunk Head/Large Flange

  • Material:

    Aluminum/Steel/Stainless Steel/Copper/Brass/Monel

  • Certificate:

    ISO9001/IATF16949

  • Finish:

    zinc plated/painted

  • Factory:

    We are a factory with 19 years of R&D experience

  • MOQ:

    10000pcs
Inquire Now

blind rivet

Material
Stainless steel, Aluminum/steel, Aluminum/Aluminum, Aluminum/ Stainless steel, Steel/ Steel Stainless Steel/ Stainless Steel,Copper/ Steel,Copper/ Bronze,Monel/ Steel
Finish
Plain, Zinc Plated(Clear/Blue/Yellow/Black), Black oxide, etc.
Standard
DIN7337
Sample Service
Samples are for free if in stock.
Packing
Bulk in cartons (25kg Max.)+wood Pallet or according to customer special demand
Lead Time
3-5 days if in stock.
Payment terms
EXW, FOB, CIF, CFR, L/C, or others.

We need more detail as follow. This will allow us to give you an accurate quotation.
Before offer the price,get the quote simply by completing and submitting the form below:
• Product:__
• Measure: _______(Inside Diameter) x_______(Outside Diameter)x_______(Thickness)
• Order Quantity: _________________pcs
• Surface treatment: _________________
• Material: _________________
• When do you need it by? __________________
• Where to Shipping: _______________ (Country with postal code please)
• Email your drawing ( jpeg, png or pdf, word)  if it is possible.

Product Details


Aluminum/ Steel Dome Head Open End Blind Rivet

Aluminum Steel Dome Head Pop RivetsStainless Blind Rivets

RIVET
DIAMETER
/mm		 PART
NUMBER		 RIVET
LENGTH
/mm		 GRIP RANGE
/mm		 HEAD
DIAMETER
/mm		 HEAD
HEIGHT
/mm		 MANDREL
DIAMETER
/mm		 MANDREL LENGTH
/mm		  HOLE SIZE
/mm		 SHEAR
/N		 TENSILE
/N
D1 L D2 k d p DRILL
+1/-0 MIN.-MAX.   MAX. MAX. MIN.   MIN. MIN.
2.4
+0.08
-0.15		 AS2404 4.0 0.5-2.0 4.2-5.0 1.0 1.55 26.00 2.5-2.6 250 N 350 N
AS2406 6.0 2.0-4.0
AS2408 8.0 4.0-6.0
AS2410 10.0  6.0-8.0
AS2412 12.0 8.0-9.5
3.0
+0.08
-0.15		 AS3006 6.0  1.5-3.5 5.4-6.3 1.3 2.00 3.1-3.2 550 N 850 N
AS3008 8.0  3.0-5.0
AS3010 10.0 5.0-7.0
AS3012 12.0  7.0-9.0
AS3014 14.0 9.0-11.0
AS3016 16.0 11.0-13.0
AS3018 18.0 13.0-15.0
AS3020 20.0 15.0-17.0
3.2
+0.08
-0.15		 AS3206 6.0 1.5-3.5 5.8-6.7 1.3 2.00 3.3-3.4 750 N 1100 N
AS3208 8.0 3.5-5.0
AS3210 10.0 5.0-7.0
AS3212 12.0  7.0-9.0
AS3214 14.0 9.0-11.0
AS3216 16.0 9.0-13.0
AS3218 18.0 13.0-15.0
AS3220 20.0 15.0-17.0
AS3225 25.0 17.0-22.0
4.0
+0.08
-0.15		 AS4006 6.0 1.0-3.0 6.9-8.4 1.7 2.45 27.00 4.1-4.2 1250 N 1800 N
AS4008 8.0 3.0-5.0
AS4010 10.0 5.0-6.5
AS4012 12.0  6.5-8.5
AS4014 14.0 8.5-10.5
AS4016 16.0 8.5-12.5
AS4018 18.0 12.5-14.5
AS4020 20.0 12.5-16.5
AS4025 25.0 16.5-21.0
AS4030 30.0 21.5-26.0
AS4035 35.0 26.0-30.0
4.8
+0.08
-0.15		 AS4806 6.0 1.5-2.5 8.3-10.1 2.0 2.95 28.00 4.9-5.0 1850 N 2600 N
AS4808 8.0 2.5-4.0
AS4810 10.0 4.0-6.0
AS4812 12.0 6.0-8.0
AS4814 14.0  7.5-9.5
AS4816 16.0 8.0-12.0
AS4818 18.0 12.0-14.0
AS4820 20.0 12.0-16.0
AS4825 25.0 16.0-21.0
AS4830 30.0 21.0-25.0
AS4835 35.0 25.0-30.0
AS4840 40.0 30.0-35.0
6.4
+0.08
-0.15		 AS6410 10.0 3.0-4.0 11.6-13.4 2.7 3.90 32.00 6.5-6.6 3400 N 4850 N
AS6412 12.0 3.0-6.0
AS6414 14.0  6.0-8.0
AS6416 16.0 6.0-10.0
AS6418 18.0 10.0-12.0
AS6420 20.0 12.0-14.0
AS6425 25.0 14.0-18.0
AS6430 30.0 18.0-23.0
AS6435 35.0 23.0-28.0
AS6440 40.0 28.0-33.0



Customized available for your rivet need

blind rivet

Production Process

Step 1

Blind rivet machine---making the rivet body

Step 2

Nail making machine---making the mandrel

Step 3

Assembly machine--finish the assembly of rivet body and the mandrel

Manufacturer Blind Rivets



Package

Regular package is small box+ carton+ pallet, or bulk in carton, each carton weights 20-25kgs.

Borie Fasteners can also provide custom packaging service, such as poly bag or plastic bag with client's logo and information.

Aluminum Steel Open End Blind Rivets



Blind Rivet Application

Blind Rivet have a wide range of applications in various industries and settings. Most of them are used in:

  • Facade
  • Solar panel bracket
  • Automoblie, Elevator
  • Air conditioner, Cabinet
  • Catering equipment
  • Aluminum windows&doors

Galvanized Blind Rivets
